Key Features:
- 16-channel power amplifier
- Hyper Dynamic Amplifier Module (HDAM® SA2) and current feedback amplification
- Massive Toroidal power transformer
- Technology Leader
- Peerless Performance
- Exquisite Design
- Newly designed exclusive Marantz SPKT-100+ pure copper.
- Double-layer copper-plated chassis.
- It integrated amplifier features an LCD (Liquid Crystal Display) to display the input source and volume level.
SPECIFICATION: Audio Wattage
400 Watts
Frequency response
5-50,000 Hz
Signal-to-noise ratio
106dB line, 88dB phono (MM), 76dB phono (MC)
Speaker Output Channel Quantity
2
|
IP Control / RS232 Control / Web Control / App Control |
No / Yes / No / No |
|
IR Flasher In |
Yes |
|
Marantz Remote Bus |
Yes |
|
DC Trigger Input/Output |
1/1 |
|
OTHERS: |
|
|
Front Display |
Level Meter |
|
Firmware Update by Network / USB / RS232C |
No / No / Yes |
|
Auto Power off |
Yes |
|
Inputs / Outputs |
|
|
Main Amplifier in |
Balanced & Unbalanced: 16ch (Exclusive use by a selector switch.) |
|
Speaker Terminal: Gold plated screw / regular screw |
Brass type (same as MODEL 40n) |
|
Number of Speaker Terminals |
16 |
|
Bi-Amp Drive/BTL Drive |
Yes / Yes |
|
Level Meter |
Yes |
|
Chassis |
Copper Plated |
|
Specifications |
|
|
Number of poweramps |
16 |
|
Power Output (8 ohm, 1 kHz, 0.05% 2ch Drive) Normal / BTL |
200W / 400W |
|
Power Output (4 ohm, 1 kHz, 0.7% 2ch Drive) Normal |
400W |
|
Power Output (8 ohm, 1 kHz, 0.7% 5ch Drive) Normal |
200W |
|
70% Guarantee (Normal/Bi-Amp/BTL) |
Yes (w/Yes JP) |
|
100% Guarantee(Normal/Bi-Amp) |
Yes |
|
General |
|
|
Metal Front Panel |
Yes |
|
Pre-Programmed / Learnable / LCD Display |
No / No / No |
|
Power Consumption in W |
500W |
|
Power Consumption No-Sound (ECO on/off) in W |
No / 140W |
|
Standby Consumption in W |
0.2 |
|
Maximum Dimensions |
W/o Antenna (W x D x H) in mm: 17.4 x 19.2 x 7.4 |
|
Weight in lbs. |
43.7 |
