- MM and MC input
- Exact loading options for any cartridge
- Fully discrete circuit board design
- Special low core saturation toroidal transformer custom designed for phono stage requirements
- Environmental friendly - absolutely zero standby power consumption
- Split Passive RIAA and DECCA EQ
- Heavy aluminium frontplate with steel chassis
- Minimal electromagnetic interference from power supply to phono preamp
- Big chassis design enables huge distance between power transformer and amplifier section
- Made in the EU
Technical Specifications:
|
MM Input |
|
|
Frequency response |
RIAA or RIAA/IEC ±0 .2dB |
|
Input sensitivity |
5mV in for 500mV out (at 1 kHz) |
|
Input impedance |
47KΩ |
|
Input capacitance |
50-400pF selectable |
|
Gain |
40 or 46dB with +6dB function |
|
THD+N |
<0.028% |
|
Signal to noise ratio |
95dB |
|
Crosstalk |
better than 100dB |
|
MC Input |
|
|
Frequency response |
RIAA or RIAA/IEC ±0.3dB |
|
Input sensitivity |
500μV in for 500mV out (at 1 kHz) |
|
Input impedance |
25Ω to 1,2KΩ selectable |
|
Gain |
60 or 66dB with +6dB function |
|
THD+N |
<0.28% |
|
Signal to noise ratio |
80dB |
|
Crosstalk |
better than 90dB |
|
Output |
|
|
Output |
1 pair RCA: left and right 500mV nom 10V max |
|
Input |
|
|
Input |
1 pair RCA |
|
Power requirement |
|
|
Mains voltages |
230V/115V; AC 50/60Hz |
|
Consumption |
20 Watts maximum. 0W in standby) |
|
Weight and Dimensions |
|
|
Unit only, unboxed |
6.59 kg |
|
In shipping carton & inc . Accessories |
10.15 kg |
|
W x H(incl. feet) x D(incl. terminals) |
440 x 105 x 390mm |
|
Standard accessories |
|
|
Standard accessories |
Mains lead: 10 Amp IEC |
