Additional Information
MM Input
- Frequency response: RIAA or RIAA/IEC ±0 .2dB
- Input sensitivity: 5mV in for 500mV out (at 1kHz)
- Input impedance: 47KΩ
- Input capacitance: 50-400pF selectable
- THD at 1 kHz: <0.005%
- Overload margin: 26dB
- Signal to noise ratio: >101dB
MC Input
- Frequency response: RIAA or RIAA/IEC ±0.25dB
- Input sensitivity: 500μV in for 500mV out (at 1kHz)
- Input impedance: 25Ω to 1,2KΩ selectable
- Input capacitance: 470pF fixed
- THD at 1 kHz: <0 .02%
- Overload margin: 26dB
- Signal to noise ratio: >90dB
Outputs (RCA/XLR)
- 1 pair RCA: left and right 500mV nom 10V max
- 1 pair XLR (balanced): left and right 1V nom 20V max
Power requirement
- Mains voltages: 230V/115V Internally set or 100V optional. AC 50/60Hz
- Consumption: 20 Watts maximum. <0 .5W in standby (orange LED on)
Weight and Dimensions
- Unit only, unboxed: 5.5 kg
- In shipping carton & inc . accessories: 11 kg
- W x H(incl. feet) x D(incl. terminals): 440 x 100 x 385mm
Standard accessories
- Mains lead: 10 Amp IEC
Musical Fidelity Warranty
- Electronics - 5 Years
- Disc Player / Electronics - 5 Years
- Disc Player / Mechanics - 2 Years
- Server - 5 Years
- Remote Control - 1 Year
