Design |
5-driver, 3 way floorstanding, ported enclosure |
|
Crossover |
2nd order electro-acoustic at 2.1 kHz (tweeter), 2nd order @ 500 Hz (bass) |
|
Frequency Response On-Axis |
±2dB from 42 Hz - 23 kHz |
|
High Frequency Driver |
1" (25mm) AL-MAC™ Ceramic Dome with Oblate Spheroid Waveguide (OSW™) and Perforated Phase-Aligning (PPA™) Tweeter Lens, ferro-fluid damped / cooled |
|
Bass Frequency Driver |
Three 7" (177mm) Ultra-HighExcursion CARBON-X™ Unibody Cone, Gen3 Active Ridge Technology (ART™) with Vertical Mounting System, Advanced SHOCK-MOUNT™ Isolation, and a 1.5” high-temp multi-layered voice coil with ventilated Apical™ former |
|
Midrange Frequency Driver |
6” (152mm) AL-MAG™ Cone with Perforated Phase-Aligning (PPA™) Lens, SHOCKMOUNT™ Isolation Mounting System, and a 2” high-temp multi-layered voice coil with ventilated Apical™ former |
|
Low Frequency Extension |
26 Hz (DIN) |
|
Sensitivity Room / Anechoic |
93 dB / 90 dB |
|
Frequency Response 30° Off-Axis |
±2dB from 42 Hz - 20 kHz |
|
Suitable Amplifier Power Range |
15 - 350 watts |
|
Maximum Input Power |
250 watts |
|
Impedance |
Compatible with 8 ohm |
|
Finishes |
Piano Black, Black Walnut, Midnight Cherry, Walnut |
|
Dimension HXWXD |
41.9” x 12.9” x 16.1” (106.5cm x 32.8cm x 40.9cm) |
|
Weight |
72 lbs (32.7 kg) each |
